RModern architectures often come with windows which not only enhance the outlook but also improve the overall air flow of the building. Unfortunately, excessive heat and glaring sunlight are among few of the unpopular problems which are created by the existence of windows. They can be very much unpleasant for human beings. However, Raytech windows film can be the perfect solution for these problems.
Features
RAYTECH™ window films deliver comfort and protection to you and your family at all times
Cooling Room Condition
Our films’ ability to reject and block the majority of heat from the sunlight is second to none. It offers a great cooling room condition which in return brings a higher level of interior comfort to the building.
Empowering Green House Effect
Recent research has proved that Raytech windows films help save energy cost by 30% as it effectively reduce the consumption of air-conditioning by eliminating external heat and containing the coolness within the building.
Long Lifespan
Made up from materials with the highest quality, Raytech windows film offers a long product life span that meets customer’s requirements for optimal solar control solution. Making sure customers’ investment is well worth it
We are committed to provide professional service and deliver the best result to our customers. In Raytech, we prioritize on our customers’ interest.
Raytech Architectural Film Range
Product Parameter Table
| Solar Film | VLT (%) | VLR (%) Interior | VLR (%) Exterior | UVR(%) | IRR(%) | Solar Factor | Shading Co | TSER (%) | SHGC |
|---|---|---|---|---|---|---|---|---|---|
| Ultra Ray X80 | 80.00 | 7.00 | 8.00 | 99.00 | 78.00 | 0.58 | 0.67 | 42.00 | 0.59 |
| Ultra Ray X70 | 68.00 | 8.00 | 9.00 | 99.00 | 98.00 | 0.46 | 0.54 | 54.00 | 0.45 |
| Ultra Ray X55 | 49.00 | 8.00 | 9.00 | 99.00 | 98.00 | 0.40 | 0.46 | 60.00 | 0.40 |
| Ultra Ray X35 | 35.00 | 7.00 | 8.00 | 99.00 | 98.00 | 0.35 | 0.40 | 65.00 | 0.35 |
| Ultra Ray X20 | 18.00 | 6.00 | 7.00 | 99.00 | 98.00 | 0.27 | 0.33 | 73.00 | 0.31 |
| Ultra Ray X5 | 6.00 | 6.00 | 7.00 | 99.00 | 98.00 | 0.25 | 0.31 | 75.00 | 0.26 |
| Atmos i80 | 82.00 | 8.00 | 9.00 | 99.00 | 43.00 | 0.70 | 0.77 | 30.00 | 0.70 |
| Atmos i70 | 71.00 | 8.00 | 9.00 | 99.00 | 62.00 | 0.58 | 0.71 | 42.00 | 0.59 |
| Atmos i55 | 39.00 | 7.00 | 8.00 | 99.00 | 62.00 | 0.53 | 0.61 | 47.00 | 0.54 |
| Atmos i35 | 36.00 | 9.00 | 10.00 | 99.00 | 63.00 | 0.45 | 0.52 | 55.00 | 0.44 |
| Atmos i20 | 23.00 | 10.00 | 11.00 | 99.00 | 67.00 | 0.39 | 0.44 | 61.00 | 0.40 |
| Atmos i5 | 5.00 | 8.00 | 9.00 | 99.00 | 72.00 | 0.34 | 0.39 | 66.00 | 0.34 |
| Ultra Ray Q45 | 46.00 | 7.00 | 8.00 | 99.00 | 65.00 | 0.47 | 0.45 | 53.00 | 0.46 |
| Quatz UL50 | 54.00 | 13.00 | 14.00 | 99.00 | 62.00 | 0.52 | 0.60 | 48.00 | 0.53 |
| Quatz UL40 | 38.00 | 14.00 | 17.00 | 99.00 | 73.00 | 0.44 | 0.51 | 56.00 | 0.44 |
| Black INF10 | 11.00 | 15.00 | 16.00 | 99.00 | 72.00 | 0.34 | 0.39 | 66.00 | 0.34 |
| Black INF20 | 21.00 | 11.00 | 12.00 | 99.00 | 83.00 | 0.38 | 0.45 | 62.00 | 0.39 |
| Deep Green 20 | 19.00 | 11.00 | 12.00 | 99.00 | 57.00 | 0.37 | 0.42 | 63.00 | 0.38 |
| Emerald Green 35 | 36.00 | 29.00 | 30.00 | 99.00 | 68.00 | 0.36 | 0.42 | 64.00 | 0.36 |
| Silver Dawn 15 | 15.00 | 13.00 | 36.00 | 99.00 | 70.00 | 0.25 | 0.30 | 75.00 | 0.26 |
| Silver Grey 25 | 27.00 | 20.00 | 35.00 | 99.00 | 70.00 | 0.39 | 0.46 | 61.00 | 0.39 |
| Silver Grey 15 | 11.00 | 24.00 | 54.00 | 99.00 | 91.00 | 0.31 | 0.35 | 69.00 | 0.31 |
| Dual Silver 35 | 28.00 | 40.00 | 44.00 | 99.00 | 75.00 | 0.28 | 0.33 | 72.00 | 0.30 |
| Dual Silver 20 | 15.00 | 58.00 | 60.00 | 99.00 | 85.00 | 0.20 | 0.21 | 80.00 | 0.20 |
| Greyish 20 | 21.00 | 30.00 | 26.00 | 99.00 | 80.00 | 0.29 | 0.33 | 71.00 | 0.30 |
| Greyish 10 | 12.00 | 26.00 | 29.00 | 99.00 | 87.00 | 0.27 | 0.32 | 73.00 | 0.28 |
| Ultra Guard CS55 | 49.00 | 8.00 | 9.00 | 99.00 | 98.00 | 0.41 | 0.47 | 59.00 | 0.41 |
| Ultra Guard CS35 | 35.00 | 7.00 | 8.00 | 99.00 | 98.00 | 0.38 | 0.45 | 62.00 | 0.39 |
| Ultra Guard CQ55 | 62.00 | 8.00 | 9.00 | 99.00 | 88.00 | 0.46 | 0.54 | 54.00 | 0.45 |
| Ultra Guard CQ35 | 38.00 | 8.00 | 9.00 | 99.00 | 88.00 | 0.36 | 0.42 | 64.00 | 0.36 |
